Cold form continuous tongue (no notching or heating), heavier main frame I-beams and side rails with 16″ cross member spacing allow a higher GVWR rating, premium radial tires, toolbox with lockable lid, LED rubber mounted sealed beam lighting in enclosed boxes with sealed modular wiring harness.
GVWR 25000 lb. – Capacity 20000 lb. with 5000 lb. Hitchload
- Treated wood deck
- 96″ wood deck 101.5″ to outside of rubrails
- 10000 lb. oil bath axles with all wheel brakes
- Slipper spring suspension
- 235/80 R16 load range E 10 ply rating West Lake Radial tires
- 12” I-beam frame (W12x16)
- 6″ channel side rails
- 3″ channel cross members – 16″ spacing
- Cold form continuous tongue (no notching or heating)
- Toolbox with lockable lid built into tongue
- 5 ft. swing-up ramps with support foot
- Pintle ring on heavy adjustable plate (no ball hitch available)
- 12000 lb. drop-foot jack
- Metal plate over wheels for lowest possible loaded deck height (35″)
- Stake pockets and rubrail
- Self charging break away kit, safety chains, full DOT reflective tape and all rubber mounted LED sealed beam lighting with U.S made sealed modular harness with 2 year warranty
- Primed, 2 coats of acrylic enamel, pin stripe
Available Sizes
-
25 ft. (20’+5′ dove tail)
-
25 ft. (21’+4′ pop-up dove tail) – Pop-up weight rating 2,500lbs.
- Call for additional lengths.
Options
- Cleated dove tail
- Pop-up dove tail
- Heavy duty split gate with spring assist
- Third ramp
- Dual jacks
- Dual speed jacks
- Spare tire and wheel (radial)
- Upgrade to all steel load range G tires
- Load range G spare tire
- Extra length (per 2′) – Call
- Color other than standard black
